Actek Hoist Ring Kits
Hoist Ring Kits are available in standard and metric sizes; and come complete with U-Bar (body and sub-assembly), screws, bushings, washers and E-Rings
Hoist Rings Kits enable you to custom assemble just the right swivel hoist ring for the job. Kits are available in standard and metric sizes.
They come complete with U-Bar (body and sub-assembly), screws, bushings, washers, and E-rings – enough to configure over 24 different hoist ring sizes and capacities.
A handy accessory kit for lifting and moving heavy loads and a must for your tool crib.
Please Email for current pricing
AK46306 HOIST RING KIT 1/2″ U-BAR, 3/4″ U-BAR, 3/8″ U-BAR
| AK46306 SAFETY SWIVEL HOIST RING KIT (KIT INCLUDES 4 OF EACH ITEM) | |||||||
| Sub- Assy | Rated Load (Lbs) |
Screw Part Number |
Screw Size | Thread Length (in.) |
Body Part Number |
Washer Part Number |
E-Ring Part Number |
| 46108 3/8″ U-Bar |
600 | 46139 | 1/4″-20 x 1-1/4″ | 1/2 in | 46112 | 46120 | 46133 |
| 800 | 46144 | 5/16″-18 x 1-1/4″ | 1/2 in | 46128 | 46126 | 46134 | |
| 1,000 | 46146 | 3/8″-16 x 1-1/4″ | 1/2 in | 46152 | 46148 | 46136 | |
| 46600 1/2″ U-Bar |
2,000 | 46614 | 7/16″-14 x 2″ | 1 in | 46618 | 46616 | 46612 |
| 2,500 | 46636 | 1/2″-13 x 2″ | 1 in | 46628 | 46626 | 46036 | |
| 46020 3/4″ U-Bar |
4,000 | 46044 | 5/8″-11 x 2-1/4″ | 1 in | 46028 | 46026 | 46034 |
| 5,000 | 46054 | 3/4″-10 x 2-1/4″ | 1 in | 46074 | 46068 | 46038 | |
AK46304 HOIST RING KIT 1″ U-BAR, 3/4″ U-BAR
| AK46304 SAFETY SWIVEL HOIST RING KIT (KIT INCLUDES 4 OF EACH ITEM) | |||||||
| Sub- Assy | Rated Load (Lbs) |
Screw Part Number |
Screw Size | Thread Length (in.) |
Body Part Number |
Washer Part Number |
E-Ring Part Number |
| 46020 3/4″ U-Bar |
2,500 | 46050 | 1/2″-13 x 2-1/4″ | 1 in | 46072 | 46066 | 46036 |
| 4,000 | 46044 | 5/8″-11 x 2-1/4″ | 1 in | 46028 | 46026 | 46034 | |
| 5,000 | 46054 | 3/4″-10 x 2-1/4″ | 1 in | 46074 | 46068 | 46038 | |
| 46220 1″ U-Bar |
7,000 | 46246 | 3/4″-10 x 3-1/4″ | 1-1/2 in | 46272 | 46266 | 46038 |
| 8,000 | 46270 | 7/8″-9 x 3-1/4″ | 1-1/2 in | 46228 | 46226 | 46234 | |
| 10,000 | 46252 | 1″-8 x 3-1/4″ | 1-1/2 in | 46274 | 46268 | 46238 | |
AK46904 HOIST RING KIT
| AK46904 METRIC SAFETY SWIVEL HOIST RING KIT (KIT INCLUDES 4 OF EACH ITEM) | |||||||
| Sub- Assy | Rated Load (Kgs) |
Screw Part Number |
Screw Size | Thread Length (mm) |
Body Part Number |
Washer Part Number |
E-Ring Part Number |
| 46020 3/4″ U-Bar |
1,050 | 49048 | M12 x 1.75 x 50 | 19 | 49072 | 49066 | 46036 |
| 1,900 | 49056 | M16 x 2.00 x 60 | 29 | 49028 | 49026 | 46034 | |
| 2,150 | 49054 | M20 x 2.50 x 65 | 34 | 49074 | 49068 | 46038 | |
| 46220 1″ U-Bar |
3,000 | 49244 | M20 x 2.50 x 75 | 32 | 49272 | 49266 | 46038 |
| 4,200 | 49250 | M24 x 3.00 x 80 | 37 | 49274 | 49268 | 46238 | |
| 4,200 | 49242 | M30 x 3.50 x 100 | 58 | 49228 | 49226 | 46834 | |
AK56304 FORGED HOIST RING KIT 3/4 AND 1 U-BAR
| AK56304 FORGED SWIVEL HOIST RING KIT (KIT INCLUDES 4 OF EACH ITEM) | |||||||
| Sub- Assy | Rated Load (Lbs) |
Screw Part Number |
Screw Size | Thread Length (in.) |
Body Part Number |
Washer Part Number |
E-Ring Part Number |
| 56020 3/4″ U-Bar |
2,500 | 56050 | 1/2″-13 | 1 in | 56030 | 56068 | 46036 |
| 4,000 | 56044 | 5/8″-11 | 1 in | 56030 | 56068 | 46034 | |
| 5,000 | 56054 | 3/4″-10 | 1 in | 56030 | 56068 | 46038 | |
| 56220 1″ U-Bar |
7,000 | 56245 | 3/4″-10 | 1-1/4 in | 56230 | 56268 | 46038 |
| 8,000 | 56243 | 7/8″-9 | 1-1/4 in | 56230 | 56268 | 46234 | |
| 10,000 | 56250 | 1″-8 | 1-1/4 in | 56230 | 56268 | 46238 | |
AK56306 FORGED HOIST RING KIT 7/16 AND 3/4 U-BAR
| AK56306 FORGED SWIVEL HOIST RING KIT (KIT INCLUDES 4 OF EACH ITEM) | |||||||
| Sub- Assy | Rated Load (Lbs) |
Screw Part Number |
Screw Size | Thread Length (in.) |
Body Part Number |
Washer Part Number |
E-Ring Part Number |
| 56108 7/16″ U-Bar |
800 | 56142 | 5/16″-18 | 1/2 in | 56130 | 56120 | 46134 |
| 1,000 | 56146 | 3/8″-16 | 1/2 in | 56130 | 56120 | 46136 | |
| 56020 3/4″ U-Bar |
2,500 | 56050 | 1/2″-13 | 1 in | 56030 | 56068 | 46036 |
| 4,000 | 56044 | 5/8″-11 | 1 in | 56030 | 56068 | 46034 | |
| 5,000 | 56054 | 3/4″-10 | 1 in | 56030 | 56068 | 46038 | |
AK56904 FORGED HOIST RING KIT METRIC 3/4 AND 1 U-BAR
| AK56904 METRIC FORGED SWIVEL HOIST RING KIT (KIT INCLUDES 4 OF EACH ITEM) | |||||||
| Sub- Assy | Rated Load (Kgs) |
Screw Part Number |
Screw Size | Thread Length (mm) |
Body Part Number |
Washer Part Number |
E-Ring Part Number |
| 56020 3/4″ U-Bar |
1,050 | 54048 | M12x1.75 | 25 | 56030 | 56068 | 46036 |
| 1,900 | 54056 | M16x2.00 | 25 | 56030 | 56068 | 46034 | |
| 2,150 | 54054 | M20x2.50 | 25 | 56030 | 56068 | 46038 | |
| 56220 1″ U-Bar |
3,000 | 54244 | M20x2.50 | 30 | 56230 | 56268 | 46038 |
| 4,200 | 54252 | M24x3.00 | 30 | 56230 | 56268 | 46238 | |
| 4,200 | 54243 | M30x3.50 | 40 | 56230 | 56268 | 46834 | |
