ADB Safety Engineered Stainless Steel Swivel Hoist Rings

Material: 300 Series Stainless Steel

Design Factor: 5:1, Hoist Rings retain the same rated load from 0 to 90 degrees from the bolt axis, Standard tolerance ± .030 inch unless otherwise specified

Range of Movement: Swivel 360°, Pivot 180° Under Load

Specifications: NDT: 100% Liquid Penetrant Tested Per MIL-STD-5002, ASTME 1417, Purification Process: Clean & Passivate Per ASTM A 967, QQ-P-35 TYPE II

Typical Applications: Use Stainless for Corrosive, Cryogenic or Elevated Temperature Environments

STAINLESS STEEL SAFETY ENGINEERED HOIST RINGS

Part No.	Rated Load (lbs)	A	B	C	D	E +/-.12	F +/-.060	G	H +/-.060	J	K	L	M	TL (lbs-ft)	Weight (lbs)
29050	275	.43	1.61	.71	3/8	.54	2.67	1/4-20	1.84	1.00	.75	.17	1.33	2.5	5 oz
29051	400	.43	1.61	.71	3/8	.29	2.67	5/16-18	1.84	1.00	.75	.17	1.27	3.5	5 oz
29052	400	.43	1.61	.71	3/8	.54	2.67	5/16-18	1.84	1.00	.75	.17	1.27	3.5	5 oz
29053	500	.43	1.61	.71	3/8	.54	2.67	3/8-16	1.84	1.00	.75	.17	1.21	6	5 oz
29301	1250	.70	2.40	.93	1/2	1.07	3.77	1/2-13	2.58	1.49	1.25	.20	1.84	14	1 lb
29004	1250	.88	3.25	1.22	3/4	.78	4.78	1/2-13	3.52	1.99	1.50	.16	2.31	14	2 lb. 5 oz
•29322	1250	.88	3.25	1.22	3/4	.78	6.72	1/2-13	3.52	1.99	1.50	.16	4.25	14	2 lb. 12 oz
29005	1250	.88	3.25	1.22	3/4	1.03	4.78	1/2-13	3.52	1.99	1.50	.16	2.31	14	2 lb. 5 oz
•29323	1250	.88	3.25	1.22	3/4	1.03	6.72	1/2-13	3.52	1.99	1.50	.16	4.25	14	2 lb
29006	1250	.88	3.25	1.22	3/4	1.28	4.78	1/2-13	3.52	1.99	1.50	.16	2.31	14	2 lb. 5 oz
•29324	1250	.88	3.25	1.22	3/4	1.28	6.72	1/2-13	3.52	1.99	1.50	.16	4.25	14	2 lb. 12 oz
29001	2000	.88	3.25	1.22	3/4	.78	4.78	5/8-11	3.52	1.99	1.50	.16	2.18	30	2 lb. 7 oz
29002	2000	.88	3.25	1.22	3/4	1.03	4.78	5/8-11	3.52	1.99	1.50	.16	2.18	30	2 lb. 7 oz
•29320	2000	.88	3.25	1.22	3/4	1.03	6.72	5/8-11	3.52	1.99	1.50	.16	4.12	30	2 lb. 14 oz
29003	2000	.88	3.25	1.22	3/4	1.28	4.78	5/8-11	3.52	1.99	1.50	.16	2.18	30	2 lb. 7 oz
•29321	2000	.88	3.25	1.22	3/4	1.28	6.72	5/8-11	3.52	1.99	1.50	.16	4.12	30	2 lb 14 oz
29007	2500	.88	3.25	1.22	3/4	1.03	4.78	3/4-10	3.52	1.99	1.50	.16	2.06	50	2 lb 9 oz
•29325	2500	.88	3.25	1.22	3/4	1.03	6.72	3/4-10	3.52	1.99	1.50	.16	4.00	50	3 lb
29009	2500	.88	3.25	1.22	3/4	1.53	4.78	3/4-10	3.52	1.99	1.50	.16	2.06	50	2 lb. 9 oz
•29327	2500	.88	3.25	1.22	3/4	1.53	6.72	3/4-10	3.52	1.99	1.50	.16	4.00	50	3 lb
29102	3500	1.40	4.80	1.71	1″	1.04	6.52	3/4-10	5.14	3.00	2.37	.24	3.06	50	6 lb. 10 oz
•29329	3500	1.40	4.80	1.71	1″	1.04	8.11	3/4-10	5.14	3.00	2.37	.24	4.65	50	7 lb. 4 oz
29103	3500	1.40	4.80	1.71	1″	1.54	6.52	3/4-10	5.14	3.00	2.37	.24	3.06	50	6 lb. 10 oz
•29330	3500	1.40	4.80	1.71	1″	1.54	8.11	3/4-10	5.14	3.00	2.37	.24	4.65	50	6 lb. 10 oz
29101	4000	1.40	4.80	1.71	1″	1.04	6.52	7/8-9	5.14	3.00	2.37	.24	2.93	80	6 lb. 12 oz
•29328	4000	1.40	4.80	1.71	1″	1.04	8.11	7/8-9	5.14	3.00	2.37	.24	4.52	80	6 lb. 12 oz
29105	5000	1.40	4.80	1.71	1″	1.29	6.52	1″-8	5.14	3.00	2.37	.24	2.81	115	7 lb
•29331	5000	1.40	4.80	1.71	1″	1.29	8.11	1″-8	5.14	3.00	2.37	.24	4.40	115	7 lb
29106	5000	1.40	4.80	1.71	1″	1.54	6.52	1″-8	5.14	3.00	2.37	.24	2.81	115	7 lb
•29332	5000	1.40	4.80	1.71	1″	1.54	8.11	1″-8	5.14	3.00	2.37	.24	4.40	115	7 lb
29107	5000	1.40	4.80	1.71	1″	2.29	6.52	1″-8	5.14	3.00	2.37	.24	2.81	115	7 lb
•29333	5000	1.40	4.80	1.71	1″	2.29	8.11	1″-8	5.14	3.00	2.37	.24	4.40	115	7 lb
29401	7500	1.75	6.00	2.11	1-1/4	1.89	8.73	1-1/4″-7	6.50	3.76	3.20	.35	4.12	235	14 lb
29202	12000	2.25	8.00	2.81	1-3/4	2.70	12.47	1-1/2″-6	8.55	4.87	4.20	.47	6.41	400	33 lb. 12 oz
†29200	15000	2.25	8.00	2.81	1-3/4	2.96	12.47	2″-4 1/2	8.55	4.87	4.20	.47	5.41	400	36 lb
†29501	25000	3.00	10.50	4.09	2-1/4	4.00	16.87	2-1/2″-8	11.67	6.52	5.75	1.12	8.03	1050	87 lb. 8 oz
†29503	25000	3.00	10.50	4.09	2-1/4	4.00	16.87	2-1/2″-4	11.67	6.52	5.75	1.12	8.03	1050	87 lb. 8 oz
†29600	37500	3.75	13.00	5.27	2-3/4	5.20	19.50	3″-4	14.15	8.10	7.25	1.00	8.48	2150	166 lb
†29701	50000	4.00	14.50	6.06	3-1/4	7.00	22.09	3-1/2″-4	15.90	8.60	7.75	1.09	9.28	3300	240 lb
